Block series · BLOCK15
15kW
A stackable 33 kWh block of silent power, charged by grid, solar or generator and scaled up to six units side by side.
Storage platform
LiFePO₄ · transformerless
- Rated energy
- 33 kWh
- Solar input
- 30 kW
- Rated current
- 21.8 A
- Electrical
- 400 V · 3P+N+PE
Applications
MicrogridsLoad shiftingRenewable self-consumptionOff-grid supplyBack-up powerEvents & filmOne complete system
Everything in one cabinet.
Battery, power conversion, control and protection arrive as one engineered unit: place it, connect it, power up.
LiFePO₄ battery
33 kWh rated capacity at 90% depth of discharge on a 550–950 V DC bus.
Transformerless inverter
98% PV-to-AC efficiency with 120% overload for 10 minutes and 150% for 10 seconds.
Dual-MPPT solar input
Up to 30 kW of PV across two trackers with a wide 160–950 V operating window.
Safety built in
Hot-aerosol fire suppression at cell and cabinet level inside an IP54 enclosure.
Block15 in off-grid deployment
The charger
Grid. Solar.Generator.
Automatic charge control across all three sources, with automated start/stop for a connected genset. The Block15 quietly tops itself up from whatever is available and hands the site clean, stable power.
- AC charging
- 15 kW
- PV input
- 30 kW max
- MPPT window
- 160–950 V
- Efficiency
- 98% PV→AC
At a glance
Built for the site.
The physical details that matter for transport, placement and connection.
Weight
670 kg
Dimensions
1040 × 1092 × 1157 mm
Noise
≤45 dB · natural cooling
Scalability
6 in parallel
Available configuration
On-board charger (OBC), 6.6 kW single-phase
Optional single-phase overnight charger for Spike/Block series.
Datasheet
Technical specifications.
BLOCK15
AC output · discharging
- Rated power
- 15 kW
- Rated voltage / frequency
- 380 / 400 V · 50 / 60 Hz
- Rated current
- 21.8 A
- Single-phase output
- 220 / 230 V · 5 kW rated · 7.5 kW for 1 h
- Rated bypass power
- 22.5 kVA
- AC connection
- 3P + N + PE
- Overload capacity
- 120% for 10 min · 150% for 10 s
AC input · charging
- Rated power
- 15 kW
- Rated voltage / current
- 380 / 400 V · 22.5 A
- Rated apparent power
- 22.5 kVA
- THDi
- ≤3%
- AC connection
- 3P + N + PE
Battery
- Chemistry
- LiFePO₄
- Rated capacity
- 33 kWh
- Depth of discharge
- 90%
- DC voltage
- 550 – 950 V
DC input · solar
- Max. power
- 30 kW
- MPPT voltage range
- 160 – 950 V
- Max. input current
- 30 / 30 A
- MPPT trackers
- 2 · 1 string each
- Start-up voltage
- 180 V
Physical & environment
- Ingress rating
- IP54
- Scalability
- Max. 6 in parallel
- Efficiency
- 98% PV→AC · 94.5% battery→AC
- Topology
- Transformerless
- Operating temperature
- −20 to +50 °C
- Relative humidity
- 0 – 100% non-condensing
- Noise emission
- ≤45 dB
- Cooling
- Natural cooling
- Fire suppression
- Hot aerosol · cell & cabinet
- Altitude
- 4,000 m · derating above 2,000 m
- Weight
- 670 kg
- Dimensions (L×W×H)
- 1040 × 1092 × 1157 mm
- AC connection
- CEE standard industrial sockets
- Compliance
- EN IEC 61000-6-2/4 · EN IEC 62109-1/2
Next step
Start with your load.
Share the load profile, duty cycle and site conditions. We will size the storage, charging feed and any generator pairing.
